 MODEL AND SUFFIX CODES
Model SufxCode Optionalcode Description
GX10 Paperless recorder (Panel mount type, Small display)
*13
GX20 Paperless recorder (Panel mount type, Large display)
*13
Type -1 Standard(Max.measurementchannels:100ch)
-2 Largememory(Max.measurementchannels:500ch)
*12
Displaylanguage E English,degF,DST(summer/wintertime)
*10
Optionalfeatures /AH Aerospace heat treatment
/AS Advancedsecurityfunction(Part11)
*21
/BC Black cover
/BT Multi-batchfunction
*22
/C2 RS-232
*1
/C3 RS-422/485
*1
/CG Custom display
*15
/D5 VGAoutput
*2
/E1 EtherNet/IPcommunication(PLCcommunicationprotocol)
*18
/E2 WTcommunication
*14
/E3 OPC-UAserver
/E4 SLMP communication (Mitsubishi PLC)
*19
/FL Fail output, 1 point
/LG Log scale
/MT Mathematicalfunction(withreportfunction)
*16 *17
/MC Communicationchannelfunction
*20
/P1 24VDC/ACpowersupply
/PG Programcontrolfunction
*23
/UH USBinterface(Host2ports)
Analoginputmodule,DigitalI/Omodule:
Pleaseaddthefollowingsufxcodestothemainunitmodelandspecicationcodes.
Option Optionalcode Description
Optionalfeatures
(Analog input)
*3*11
/UC10 Withanaloginputmodule,10ch(Clampterminal)
/UC20 Withanaloginputmodule,20ch(Clampterminal)
*7
/UC30 Withanaloginputmodule,30ch(Clampterminal)
*8
/UC40 Withanaloginputmodule,40ch(Clampterminal)
*5
/UC50 Withanaloginputmodule,50ch(Clampterminal)
*5
/US10 Withanaloginputmodule,10ch(M3screwterminal)
/US20 Withanaloginputmodule,20ch(M3screwterminal)
*7
/US30 Withanaloginputmodule,30ch(M3screwterminal)
*8
/US40 Withanaloginputmodule,40ch(M3screwterminal)
*5
/US50 Withanaloginputmodule,50ch(M3screwterminal)
*5
Optionalfeatures
(DigitalI/O)
*4
/CR01 WithdigitalI/Omodule,(Output:0,Input:16)
*8 *9 *16
/CR10 WithdigitalI/Omodule,(Output:6,Input:0)
*8
/CR11 WithdigitalI/Omodule,(Output:6,Input:16)
*7 *8 *9 *16
/CR20 WithdigitalI/Omodule,(Output:12,Input:0)
*6
/CR21 WithdigitalI/Omodule,(Output:12,Input:16)
*6 *9 *16
/CR40 WithdigitalI/Omodule,(Output:24,Input:0)
*6
/CR41 WithdigitalI/Omodule,(Output:24,Input:16)
*6 *9 *16
*1 /C2and/C3cannotbespeciedtogether.
*2 /D5canbespeciedonlyfortheGX20.
*3 Onlyoneoptioncanbespecied.
