Calibrationcerticate(soldseparately)
WhenorderingtheGX10/GX20withoptions(analoginput),thecalibrationcerticateforthemodulesisincludedin
andshippedwiththecalibrationcerticateofthemainunit.Whenorderingananaloginputmoduleseparately,each
modulegetsitsowncalibrationcerticate(onecerticatepermodule).
Testcerticate(QIC,soldseparately)
WhenorderingtheGX10/GX20withoptions(analog/digialI/O),theQICforeachmoduleisincludedinandshipped
withtheQICofthemainunit.WhenorderinganaloginputmodulesanddigitalI/Omodulesseparately,eachmodule
getsitsownQIC(oneQICpermodule).
User'sManual
Productuser'smanualscanbedownloadedorviewedatthefollowingURL.Toviewtheuser'smanual,youneedto
use Adobe Reader 7 or later by Adobe Systems.
URL:www.smartdacplus.com/manual/en/
ProductPurchaseSpecications
TheGX10/GX20iscomposedofthemainunit,I/Omodules,ExpandableI/O,andExpansionmodule.
TherearetwowaystopurchaseI/Omodules.
OnewayistopurchasethemindividuallybyspecifyingmodelsGX90XA,GX90XD,GX90YD,GX90WD,and
GX90XP,GX90YA,GX90UT.
Theotherwayistopurchasethemasanoption(/UCxxor/USxx).Purchasingthemasanoptionisconvenient,but
thisplaceslimitationsonthenumberofanaloginputsthatyoucanobtain.
Ifyouwanttousemorethan50channels,pleasepurchasetheI/Omodulesindividually.
ToconnectexpandableI/O(GX60),GMsubunittoGX10orGX20,youmustpurchaseoneunitofexpansion
module(GX90EX)forGX10/GX20inadditiontotheexpandableI/O,GMsubunit.
