Displaydata:
• Target:Measurement(input/outputmodule)/
math/communicationchannels,alarmsummary,
messagesummary
 Description:Maximumorminimumvalueper
recordlinginterval
• Recordingintervals:Determinedbythetrend
interval,recordingdatatype(displaydata/display
data+eventdata,GP20-2)
• Numberofchannelsthatcanberecorded
 ForGP20-1
Trendinterval(div) Numberofchannels
5 s 100
10 s 200
15 s or longer 500
 ForGP20-2
Trendinterval(div) Numberofchannels
Display
data
Displaydata+
Eventdata
5 s 200 100
10 s 500 200
15 s 1000 500
30 s or longer 1000 1000
 Notethatthemaximumnumberofchannelsis
xedat100intheGP10.
• Datasize;
Analog input data: 12 bytes/ch.
Analog output data: 12 bytes/ch.
DigitalI/Odata:4bytes/ch.
Pulse input data: 12 bytes/ch.
Math channel data: 12 bytes/ch.
 Communicationchanneldata:12bytes/ch.
• Filesize:Upto18MB
• NumberoflesforGP10,GP20-1:Upto500
(includingeventdata),forGP20-2;Upto1000
(includingeventdata)
Operationintheinternalmemory:FIFO(FirstIn
FirstOut)
• Dataformat:Binaryortext
• Recording:Recordsdataatalltimes.
• Displaydatalesampletime
Measurementchannel=30.MathChannel=0
InternalMemory 500 MB
Trendinterval(minute/div) 30minutes
Recordinginterval(s) 60 s
Totalsampletime Approx.2.5years
Eventdata:
• Target:Measurement(input/outputmodule)/
math/communicationchannels,alarmsummary,
messagesummary,operationlog
 Description:Instantaneousvalueperrecording
interval
• Recordingintervals:Determinedbythescan
interval,recordingdatatype(displaydata/display
data+eventdata)
• Numberofchannelsthatcanberecorded:
 Measurmentmode:Normal
 ForGP20-1
Recordinginterval Numberofchannels
*1
100ms 100
200ms 200
500msorlonger 500
 ForGP20-2
Recordinginterval Numberofchannels
*1
Display
data
Displaydata+
Eventdata
100ms 500 100
200ms 500 200
500ms 1000 500
1 s or longer 1000 1000
 Notethatthemaximumnumberofchannelsis
100 in the GP10.
 Measurmentmode:Highspeed
Recordinginterval Numberofchannels
*1
GP10 GP20-1 GP20-2
1ms 2 2 10
2ms 4 4 20
5ms 10 10 50
10ms 20 20 100
20ms 40 40 150
50ms 100 100 150
100ms 100 100 200
200ms 100 200 500
500ms 100 500 1000
1 s or longer 100 500 1000
Measurmentmode:Dualinterval
Recordinginterval Numberofchannels
*1 *2
GP10 GP20-1 GP20-2
1ms — — 5
2ms — — 10
5ms 5 5 25
10ms 10 10 40
20ms 20 20 50
50ms 50 50 50
100ms 100 100 100
200ms 100 100 200
500ms 100 250 600
1 s or longer 100 250 600
*1 TotalnumberincludingI/Ochannels,math
channels,andcommunicationchannels
*2 Numberofchannelsthatcanberecordedisthe
sameforscangroup1andscangroup2.
