 OVERVIEW
GX60 I/O Base Unit (Expandable I/O)
The GX60 provides a function to expand an I/O
module for recording and controlling, when it is
connected to the expansion module that is connected
to the GX10/GX20/GP10/GP20/GM using a LAN cable
via a private communication network.
● OneGX60caninstalluptosixI/Omodules.
● Uptosixunitscanbeadditionallyconnectedto
the GX/GP/GM.
● ThecommunicationdistancebetweentheGX/
GP/GM and GX60 or between GX60s can be
extendedbyupto100musingaLANcable.
* WhenthemeasurementmodeontheGX/GP/
GM is High speed, expandable I/O units cannot
be installed in the GX/GP/GM.
GX90EX Expansion Module
The expansion module is installed in the GX10/GX20/
GP10/GP20, GX60, GM main unit, and GM sub unit.
[IfGX90EXexpansionmoduleisinstalledintheGX/GP
or I/O base unit]
● Theexpansionmodule,whichissupportedby
the GX/GP and GX60, enables a connection
betweenGX/GPandGX60oracommunication
between GX60s.
● Adistributedarrangementwiththedata
timesynchronizationsecuredisprovidedby
connectingExpansionmodulesinstalledinthe
GX/GPmainunitandGX60usingaLANcable.
● Dataistransferredtothehigh-orderGX/GPvia
theexpansionmodule.
[IfGX90EXexpansionmoduleisinstalledintheGM
mainunit/subunit]
● Theexpansionmodule,whichissupported
bytheGMmainunitandsubunit,enablesa
connectionbetweenGMmainunitandsubunit
oracommunicationbetweensubunits.
● Adistributedarrangementwiththedata
timesynchronizationsecuredisprovidedby
connectingExpansionmodulesinstalledinthe
GMmainunitandsubunitusingaLANcable.
● Dataistransferredtothehigh-orderGM10via
theexpansionmodule.
GX90EX
GX60
Power inlet type
Power Screw type
