YOKOGAWA GX20

4
All Rights Reserved. Copyright © 2014, Yokogawa Electric Corporation
GS 04L53B01-01EN May. 19, 2017-00
Continued
Input Type Range Measurement range
Measurement accuracy (digital display) Max.
resolution
of digital
display
A/D integration time: 16.7ms or more
*22
A/D integration time: 1.67ms
*23
RTD
(Measured
current:
1mA)
Pt100
*12
-200.0 to 850.0°C ±(0.15%ofrdg+0.3°C) ±(0.3%ofrdg+1.5°C) 0.1°C
-150.00 to 150.00°C 0.01°C
JPt100
*12
-200.00 to 550.00°C 0.1°C
-150.00 to 150.00°C 0.01°C
Cu10 GE -200.0 to 300.0°C ±(0.2%ofrdg+2.0°C)
guaranteed range
Cu10 GE: -70.0 to 170.0°C
Cu10 L&N: -75.0 to 150.0°C
Cu10 WEED: -200.0 to 260.0°C
Other range: -200.0 to 300.0°C
±(0.4%ofrdg+6.0°C)
guaranteed range
Cu10 GE: -70.0 to 170.0°C
Cu10 L&N: -75.0 to 150.0°C
Cu10 WEED: -200.0 to 260.0°C
Other range: -200.0 to 300.0°C
0.1°C
Cu10 L&N -200.0 to 300.0°C
Cu10 WEED -200.0 to 300.0°C
Cu10 BAILEY -200.0 to 300.0°C
Cu10 at 20°C
α=0.00392
-200.0 to 300.0°C
Cu10 at 20°C
α=0.00393
-200.0 to 300.0°C
Cu25 at 0°C
α=0.00425
-200.0 to 300.0°C ±(0.3%ofrdg+0.8°C) ±(0.5%ofrdg+3.0°C) 0.1°C
Cu53 at 0°C
α=0.00426035
-50.0 to 150.0°C ±(0.15%ofrdg+0.8°C) ±(0.3%ofrdg+4.0°C) 0.1°C
Cu100 at 0°C
α=0.00425
-50.0 to 150.0°C ±(0.2%ofrdg+1.0°C) ±(0.4%ofrdg+5.0°C) 0.1°C
J263B
*13
0.0 to 300.0 K ±1.0 K
Less than 40.0 K: ±3.0 K
±3.0 K
Less than 40.0 K: ±9.0 K
0.1 K
Ni100(SAMA) -200.0 to 250.0°C ±(0.15%ofrdg+0.4°C) ±(0.3%ofrdg+2.0°C) 0.1°C
Ni100(DIN)
*14
-60.0 to 180.0°C
Ni120
*15
-70.0 to 200.0°C
Pt25
*16
-200.0 to 550.0°C ±(0.15%ofrdg+0.8°C) ±(0.3%ofrdg+4.0°C) 0.1°C
Pt50
*17
-200.0 to 550.0°C ±(0.3%ofrdg+0.6°C) ±(0.6%ofrdg+3.0°C) 0.1°C
Pt200 WEED -100.0 to 250.0°C ±(0.3%ofrdg+1.0°C)
Cu10 GOST
*18
-200.0 to 200.0°C ±(0.2%ofrdg+2.0°C) ±(0.4%ofrdg+6.0°C) 0.1°C
Cu50 GOST
*19
-200.0 to 200.0°C ±(0.15%ofrdg+0.6°C) ±(0.3%ofrdg+4.0°C) 0.1°C
Cu100 GOST
*20
-200.0 to 200.0°C ±(0.15%ofrdg+0.3°C) ±(0.3%ofrdg+1.5°C) 0.1°C
Pt46 GOST
*19
-200.0 to 550.0°C ±(0.3%ofrdg+0.8°C) ±(0.6%ofrdg+4.0°C) 0.1°C
Pt100 GOST
*20
-200.0 to 600.0°C ±(0.15%ofrdg+0.3°C) ±(0.3%ofrdg+2.0°C) 0.1°C
4-wireRTD
(Measured
current:
1mA)
Pt100
*12
-200.0 to 850.0°C ±(0.05%ofrdg+0.3°C) ±(0.1%ofrdg+1.5°C) 0.1°C
-150.00 to 150.00°C 0.01°C
JPt100
*12
-200.0 to 550.0°C 0.1°C
-150.00 to 150.00°C 0.01°C
Cu10 GE -200.0 to 300.0°C ±(0.1%ofrdg+2.0°C)
guaranteed range
Cu10 GE: -70.0 to 170.0°C
Cu10 L&N: -75.0 to 150.0°C
Cu10 WEED: -200.0 to 260.0°C
Other range: -200.0 to 300.0°C
±(0.2%ofrdg+5.0°C)
guaranteed range
Cu10 GE: -70.0 to 170.0°C
Cu10 L&N: -75.0 to 150.0°C
Cu10 WEED: -200.0 to 260.0°C
Other range: -200.0 to 300.0°C
0.1°C
Cu10 L&N -200.0 to 300.0°C
Cu10 WEED -200.0 to 300.0°C
Cu10 BAILEY -200.0 to 300.0°C
Cu10 at 20°C
α=0.00392
-200.0 to 300.0°C
Cu10 at 20°C
α=0.00393
-200.0 to 300.0°C
Cu25 at 0°C
α=0.00425
-200.0 to 300.0°C ±(0.1%ofrdg+0.8°C) ±(0.2%ofrdg+2.0°C) 0.1°C
Cu53 at 0°C
α=0.00426035
-50.0 to 150.0°C ±(0.05%ofrdg+0.6°C) ±(0.1%ofrdg+1.5°C) 0.1°C
Cu100 at 0°C
α=0.00425
-50.0 to 150.0°C ±(0.05%ofrdg+0.3°C) ±(0.1%ofrdg+1.5°C) 0.1°C
J263B
*13
0.0 to 300.0K ±0.4 K
Less than 40.0 K: ±0.8 K
±1.5 K
Less than 40.0 K: ±3.0 K
0.1K
Ni100(SAMA) -200.0 to 250.0°C ±(0.05%ofrdg+0.3°C) ±(0.1%ofrdg+1.5°C) 0.1°C
Ni100(DIN)
*14
-60.0 to 180.0°C 0.1°C
Ni120
*15
-70.0 to 200.0°C 0.1°C
Pt25
*16
-200.0 to 550.0°C ±(0.1%ofrdg+0.8°C) ±(0.2%ofrdg+2.0°C) 0.1°C
Pt50
*17
-200.0 to 550.0°C ±(0.05%ofrdg+0.6°C) ±(0.1%ofrdg+1.5°C) 0.1°C
Pt200 WEED -100.0 to 250.0°C ±(0.05%ofrdg+1.0°C) ±(0.1%ofrdg+3.0°C) 0.1°C
Cu10 GOST
*18
-200.0 to 200.0°C ±(0.1%ofrdg+2.0°C) ±(0.2%ofrdg+5.0°C) 0.1°C
Cu50 GOST
*19
-200.0 to 200.0°C ±(0.05%ofrdg+0.6°C) ±(0.1%ofrdg+1.5°C) 0.1°C
Cu100
GOST
*20
-200.0 to 200.0°C ±(0.05%ofrdg+0.3°C) ±(0.1%ofrdg+1.5°C) 0.1°C
Pt46 GOST
*19
-200.0 to 550.0°C ±(0.05%ofrdg+0.6°C) ±(0.1%ofrdg+1.5°C) 0.1°C
Pt100 GOST
*20
-200.0 to 600.0°C ±(0.05%ofrdg+0.3°C) ±(0.1%ofrdg+1.5°C) 0.1°C
4-wireRTD
(Measured
current:
0.25mA)
Pt500 -200.0 to 850.0°C ±(0.05%ofrdg+0.3°C) ±(0.1%ofrdg+1.5°C) 0.1°C
Pt1000 -200.0 to 850.0°C
Resistance
(4-wire)
20Ω(Meas-
ured current:
1mA)
0.0 to 20.000Ω ±(0.05%ofrdg+0.007Ω) ±(0.1%ofrdg+0.025Ω) 0.001Ω
200Ω(Meas-
ured current:
1
mA)
0.0 to 200.00Ω ±(0.05%ofrdg+0.03Ω) ±(0.1%ofrdg+0.15Ω) 0.01Ω
2000
Ω(Measured
current: 0.25
mA)
0.0 to 2000.0Ω ±(0.05%ofrdg+0.3Ω) ±(0.1%ofrdg+1.0Ω) 0.1Ω
