 MODEL AND SUFFIX CODES
Analog input module, Digital I/O module (sold separately):
MODEL and SUFFIX Code (GX90XA)
Model Sufx Code Description
GX90XA Analog Input Module
Numberofchannels -04 4channels(Type-H0only)
-06 6channels(Type-R1only)
-10 10channels(Type-C1,-L1,-U2,-T1)
Type -C1 Current,scannertype(isolatedbetweenchannels)
-L1 DCV/TC/DI,lowwithstandvoltagescannertype(isolatedbetweenchan-
nels)
-U2 Universal,Solidstaterelayscannertype(3-wireRTDb-terminalcommon)
-T1 DCV/TC/DI,Electromagneticrelayscannertype(Isolatedbetweenchan-
nels)
-H0 High-speeduniversal,individualA/Dtype(isolatedbetweenchannels)
-R1 4-wireRTD/resistance,scannertype(isolatedbetweenchannels)
- N Always N
Terminalform -3 Screwterminal(M3)
-C Clampterminal
Area N General
MODEL and SUFFIX Code (GX90XD)
Model Sufx Code Description
GX90XD Digital Input Module*
Numberofchannels -16 16 channels
Type -11 Opencollector/Non-voltage,contact(sharedcommon),Rated5VDC
- N Always N
Terminalform -3 Screwterminal(M3)
-C Clampterminal
Area N General
* Ifyouwanttointegratepulseinput,amathfunction(/MToption)isrequiredintheGX/GP/GMmainunit.
MODEL and SUFFIX Code (GX90YD)
Model Sufx Code Description
GX90YD Digital Output Module
Numberofchannels -06 6 channels
Type -11 Relay,SPDT(NO-C-NC)
- N Always N
Terminalform -3 Screwterminal(M3)
Area N General
MODEL and SUFFIX Code (GX90WD)
Model Sufx Code Description
GX90WD Digital Iutput/Output Module*
Numberofchannels -0806 8 channel DIs, 6 channel DOs
Type -01 Opencollector/non-voltagecontact(sharedcommon),rated5VDC;
Relay,SPDT(NO-C-NC)
- N Always N
Terminalform -3 Screwterminal(M3)
Area N General
* Ifyouwanttointegratepulseinput,amathfunction(/MToption)isrequiredintheGX/GP/GMmainunit.
