Note
When the chattering filter is set to On, the input range can be up to 30 Hz.
SpanLower,Span Upper
Set the input range. You cannot set the same value to Span Lower and Span Upper.
• When Calculation is set to Off or Linear scaling.
0 to 200000
• When Calculation is set to Delta
-200000 to 200000
Example:Measuredvalueperscanintervalwhen10000(pulse/s)isinput
Scan interval 100 ms 200 ms 500 ms 1 s 2 s 5 s
Measured
value
1000 2000 5000 10000 20000 50000
Calculation
When performing input calculation, set the calculation type.
For details, see page 1-27 in section 1.2.1, “Setting the Range”.
• Linearscaling
Converts the unit to obtain the measured value.
• Delta
The measured value of the channel is set to the difference with respect to the measured
value of the reference channel.
Reference Channel
Set the reference channel for the difference calculation.
For details, see page 1-27 in section 1.2.1, “Setting the Range”.
Scale
1
Setup Item Selectable Range or Options Default Value
Decimal place 0/1/2/3/4/5 2
Scale Lower –999999 to 999999 0.00
Scale Upper –999999 to 999999 100.00
Unit
Character string (up to 6 characters,
A
a
#
1
)
—
1 Appears when Calculation is set to Linear scaling.
See page 1-27 in section 1.2.1, “Setting the Range”.
Moving average
Setup Item Selectable Range or Options Default Value
On/Off Off, On Off
Count
1
2 to 100 2
1 Appears when On/Off is set to On.
See page 1-27 in section 1.2.1, “Setting the Range”.
Note
If you change the GX/GP’s date or time or when the time is being gradually adjusted, the scan
interval will change. This will change the measured values of each scan interval, but it will not affect
the integration result (TLOG.PSUM). The default span upper and span lower limits assume values
that are affected the most by a time change at the scan interval of 5 s.
1.4ConfiguringPulseInputChannels(Releasenumber3andlater)
