YOKOGAWA GX20 User Manual

1-75
IM 04L51B01-01EN
Configuring the GX/GP and Viewing the Settings
1
2
3
4
5
App
Index
Color
Setup Item Selectable Range or Options Default Value
Color 24 colors (red, green, blue, blue violet, brown,
orange, yellow-green, light blue, violet, gray,
lime, cyan, dark blue, yellow, light gray, purple,
black, pink, light brown, light green, dark gray,
olive, dark cyan, and spring green) and a user-
defined color (1 color)
—
Color
Set channel display colors. The colors apply to the trend display and bar graph display.
For instructions on how to set the user-defined color, see page 1-40 in section 1.2.3,
“Setting the Display”.
Zone
Setup Item Selectable Range or Options Default Value
Lower 0 to 95% 0
Upper 5 to 100% 100
LowerandUpper
Set these values when you want to divide the waveform displays of channels into
separate zones so that waveforms do not overlap. Set the Lower and Upper positions as
percentages of the maximum display width. Set Lower to a value less than Upper, and set
the zone width (Upper – Lower) to be 5% or greater.
Scale
Setup Item Selectable Range or Options Default Value
Position GX20/GP20: Off/1/2/3/4/5/6/7/8/9/10
GX10/GP10: Off/1/2/3/4/5/6
1
Division 4/5/6/7/8/9/10/11/12/C10 10
Position
Set the scale display positions when you want to display multiple scales on the trend display.
Set this to Off to not display scales.
Division
Set the number of divisions to make with the main scale marks.
C10: The scale is equally divided into 10 sections by main scale marks, and scale values are
indicated at 0, 30, 50, 70, and 100% positions.
For display examples, see the scale settings on page 1-40 in section 1.2.3, “Setting the
Display”.
Bar graph
Setup Item Selectable Range or Options Default Value
Base position Lower, Center, Upper Lower
Division 4/5/6/7/8/9/10/11/12 10
Base position
Set the bar graph base position. This setting is applied when you are displaying the current
value on the scale as a bar graph on the bar graph and trend displays (only on the GX/GP
main unit display).
Division
Set the number of divisions to make with the main scale marks.
For display examples, see page 1-40 in section 1.2.3, “Setting the Display”.
1.5ConfiguringAOChannels(Analoginputchannels)
