YOKOGAWA SMARTDAC+ GP10 User Manual

3
All Rights Reserved. Copyright © 2014, Yokogawa Electric Corporation
GS 04L53B01-01EN Nov. 10, 2015-00
Continued
Input Type Range Measurement range
Measurement accuracy (digital display) Max.
resolution
of digital
display
A/D integration time: 16.7ms or more
*23
A/D integration time: 1.67ms
*24
TC
(Excluding
RJCac-
curacy)
PR20-40
*9
0.0 to 1900.0°C ±(0.7 % of rdg + 0.4°C)
However, accuracy at less than 800.0°C is not
guaranteed.
±20.0°C
However, accuracy at less than 800.0°C is not
guaranteed.
0.1°C
NiNiMo
*8
0.0 to 1310.0°C ±(0.25 % of rdg + 0.7°C) ±(0.5% of rdg + 5.0°C) 0.1°C
W/WRe26
*10
0.0 to 2320.0°C ±(0.2 % of rdg + 2.0°C)
However, accuracy at less than 300.0°C is not
guaranteed.
±(0.4 % of rdg + 12.0°C)
However, accuracy at less than 300.0°C is not
guaranteed.
0.1°C
N(AWG14)
*11
0.0 to 1300.0°C ±(0.2 % of rdg + 1.3°C) ±(0.5% of rdg + 7.0°C) 0.1°C
XK GOST
*12
-200.0 to 600.0°C ±(0.25 % of rdg + 0.8°C) ±(0.5% of rdg + 4.0°C) 0.1°C
RTD Pt100
*13
-200.0 to 850.0°C ±(0.15 % of rdg + 0.3°C) ±(0.3 % of rdg + 1.5°C) 0.1°C
-150.00 to 150.00°C 0.01°C
JPt100
*13
-200.00 to 550.00°C 0.1°C
-150.00 to 150.00°C 0.01°C
Cu10 GE -200.0 to 300.0°C ±(0.2 % of rdg + 2.0°C)
guaranteed range
Cu10 GE: -70.0 to 170.0°C
Cu10 L&N: -75.0 to 150.0°C
Cu10 WEED: -200.0 to 260.0°C
Other range: -200.0 to 300.0°C
±(0.4 % of rdg + 6.0°C)
guaranteed range
Cu10 GE: -70.0 to 170.0°C
Cu10 L&N: -75.0 to 150.0°C
Cu10 WEED: -200.0 to 260.0°C
Other range: -200.0 to 300.0°C
0.1°C
Cu10 L&N -200.0 to 300.0°C
Cu10 WEED -200.0 to 300.0°C
Cu10 BAILEY -200.0 to 300.0°C
Cu10 at 20°C
α=0.00392
-200.0 to 300.0°C
Cu10 at 20°C
α=0.00393
-200.0 to 300.0°C
Cu25 at 0°C
α=0.00425
-200.0 to 300.0°C ±(0.3 % of rdg + 0.8°C) ±(0.5 % of rdg + 3.0°C) 0.1°C
Cu53 at 0°C
α=0.00426035
-50.0 to 150.0°C ±(0.15 % of rdg + 0.8°C) ±(0.3 % of rdg + 4.0°C) 0.1°C
Cu100 at 0°C
α=0.00425
-50.0 to 150.0°C ±(0.2 % of rdg + 1.0°C) ±(0.4 % of rdg + 5.0°C) 0.1°C
J263B*14 0.0 to 300.0 K ±1.0 K
Less than 40.0 K: ±3.0 K
±3.0 K
Less than 40.0 K: ±9.0 K
0.1 K
Ni100
(SAMA)
-200.0 to 250.0°C ±(0.15 % of rdg + 0.4°C) ±(0.3 % of rdg + 2.0°C) 0.1°C
Ni100 (DIN)
*15
-60.0 to 180.0°C
Ni120
*16
-70.0 to 200.0°C
Pt25
*17
-200.0 to 550.0°C ±(0.15 % of rdg + 0.8°C) ±(0.3 % of rdg + 4.0°C) 0.1°C
Pt50
*18
-200.0 to 550.0°C ±(0.3 % of rdg + 0.6°C) ±(0.6 % of rdg + 3.0°C) 0.1°C
Pt200 WEED -100.0 to 250.0°C ±(0.3 % of rdg + 1.0°C)
Cu10 GOST
*19
-200.0 to 200.0°C ±(0.2 % of rdg + 2.0°C) ±(0.4 % of rdg + 6.0°C) 0.1°C
Cu50 GOST
*20
-200.0 to 200.0°C ±(0.15 % of rdg + 0.6°C) ±(0.3 % of rdg + 4.0°C) 0.1°C
Cu100 GOST
*21
-200.0 to 200.0°C ±(0.15 % of rdg + 0.3°C) ±(0.3 % of rdg + 1.5°C) 0.1°C
Pt46 GOST
*20
-200.0 to 550.0°C ±(0.3 % of rdg + 0.8°C) ±(0.6 % of rdg + 4.0°C) 0.1°C
Pt100 GOST
*21
-200.0 to 600.0°C ±(0.15 % of rdg + 0.3°C) ±(0.3 % of rdg + 2.0°C) 0.1°C
DI Level Thresholdlevel(Vth=2.4V)Accuracy:±0.1V -
Contact
*22
Lessthan1kΩ:1(ON),Morethan100kΩ:0(OFF)(parallelcapacitanceof0.01μF
or less)
-
rdg:Readingvalue
*4 R,S,B,K,E,J,T,N:IEC60584-1,DINEN60584,JIS
C1602
*5 
W:W-5%Re/W-26%Re(HoskinsMfg.Co.)ASTME988-96
 (TypeCequivalentofOMEGAEngineeringInc.)
*6 L:Fe-CuNi,DIN43710,U:Cu-CuNi,DIN43710
*7 WRe3-25:W-3%Re/W-25%Re(HoskinsMfg.Co.)ASTM
E988-96
 (TypeDequivalentofOMEGAEngineeringInc.)
*8 KpvsAu7Fe,PLATINELII,NiNiMo:ASTME1751
*9 PR20-40:PtRH20%-PtRh40%(JohnsonMattheyPlc)
ASTM E1751
*10 W/WRe26:W/W-26%Re(HoskinsMfg.Co.)ASTME1751
 (TypeGequivalentofOMEGAEngineeringInc.)
*11 N(AWG14):NBS
*12 XKGOST:TypeL(GOSTR8.525-2001)
*13 
Pt100: JIS C1604, IEC60751, DIN EN60751
JPt100: JIS C1604, JIS C1606
*14 J263B:YokogawaElectricCorporationJ263*B
*15 Ni100(DIN):DIN43760
*16 Ni120:McGRAWEDISONCOMPANY
*17 Pt25:One-fourthofJPt100resistancevalue
*18 Pt50:JISC1604,JISC1606
*19 
Cu10 GOST: One-tenth of Cu100 GOST resistance value
*20 Cu50GOST,Pt46GOST:GOST6651-94
*21 Cu100GOST,Pt100GOST:GOST6651-2009
*22
Thedetectedcurrentvalueisapprox.10μA.
*23 10channelmodewithscanintervalsetto500msorhigher,or
2channelmode
*24 10channelmodewithscanintervalsetto100msor200ms
 Measurementaccuracyatscaling:measurement
accuracyatscaling(digits)=measurement
accuracy (digits) x scaling span (digits)/
measurementspan(digits)+2digits
*Roundingupdecimalplaces
