Accessories
209
Device Insertion and Removal
Figure 186 Insert Device into Cradle
Figure 187 Remove Device from Cradle
To ensure the device was inserted correctly, listen for the audible click that signifies that the device locking
mechanism was enabled and the device was locked into place.
CAUTION: Ensure that the device is fully inserted into the cradle. Lack of proper insertion may result in property damage or
personal injury. Zebra Technologies Corporation is not responsible for any loss resulting from the use of the products while
driving.
To remove the device from the cradle, press the release latch, grasp the device and lift out of the vehicle
cradle.
Device Battery Charging
Insert the device into the cradle. The device starts to charge through the cradle as soon as it is inserted. This
does not deplete the vehicle battery significantly. The battery charges in approximately four hours. See Table 3
on page 27 for all charging indications.
Charging Note
The Vehicle Cradle operating temperature is -40°C to +85°C. When in the cradle, the device will only charge
when its temperature is between 0°C to +40°C.
