Zebra TC70 Series User Manual

Using the Device
47
Status Icons
Table 5 Status Icons
Icon Description
Alarm is active.
Main battery is fully charged.
Main battery is partially drained.
Main battery charge is low.
Main battery charge is very low.
Main battery is charging.
All sounds, except media and alarms, are silenced and vibrate mode is active.
Do Not Disturb mode active.
Airplane Mode is active. All radios are turned off.
Bluetooth is on.
The device is connected to a Bluetooth device.
Connected to a Wi-Fi network.
Not connected to a Wi-Fi network or no Wi-Fi signal.
Connected to an Ethernet network.
Speakerphone enabled.
Portable Wi-Fi hotspot is active (WWAN only).
Connected to a 4G LTE/LTE-CA network (WWAN only)
1
.
Connected to a DC-HSPA, HSDPA, HSPA+, HSUPA, LTE/LTE-CA or WCMDMA network
(WWAN only)
1
.
Connected to a 1x-RTT (Sprint), EGDGE, EVDO, EVDV or WCDMA network (WWAN only)
1
.
Connected to a DC - HSPA, HSDPA, HSPA+ or HSUPA network (WWAN only)
1
.
Connected to an EDGE network (WWAN only)
1
.
1
Cellular network icon that appears is dependent upon the carrier/network.

Zebra TC70 Series Specifications

General

Display Size	4.7 inches
Display Resolution	1280 x 720
Operating System	Android
Storage	16 GB
Expansion Slot	microSD
Camera	8 MP rear
Ruggedness	IP67
Wireless Connectivity	802.11a/b/g/n
Cellular Connectivity	4G LTE
GPS	Yes
Data Capture	1D/2D barcode scanning
Operating Temperature	-10°C to 50°C
RAM	2 GB
