Zebra ZD410 - Page 158

Dimensions
158
Dimensions are in
millimeters (mm)
Mounting Hole
Mounting Hole
Hardware Reset Access
(Provide 20-25 mm hole in
mounting plate or surface)
Use M3 thread forming screws with maximum hole depth of 5 mm into the printer body.
Note - Do not remove the rubber feet or the printer can overheat.
