Install Hardware Options
37
Installing the Attached Battery Base Options
The battery base is ready to attach to the printer. The base is installed using a Torx T10 wrench and the
mounting screws provided with the upgrade kit.
1. Remove any media rolls from the printer. Remove the original power supply cable from the back of the
printer.
2. Turn the printer over and align the power base to the bottom of the printer with the printer power plug
oriented toward the rear of the printer. The printer’s rubber feet align with recesses in the top of the
power base.
3. Use the two (2) screws provided to attach the power base to the printer. Tighten the screws using the
Torx wrench supplied in the kit.
