Install Hardware Options
33
Installing the Label Dispenser
The standard bezel must be removed before the Label Dispenser can be installed.
1. Place the Label Dispenser module and printer right side up with the top of the module 12.5 mm (0.5
inch) below the bottom of the top cover. Center and push the module into the front of the printer and
slide it up until it stops.
2. Turn the printer upside down and attach the module to the printer with the two screws.
