Zebra ZD410 - Installing the Cutter

Install Hardware Options
34
Installing the Cutter
The standard bezel must be removed before the cutter module can be installer.
1. Place the Cutter module and printer right side up with the top of the module even with the bottom of the
top cover. Center and push the module into the front of the printer and slide it up until it stops.
2. Turn the printer upside down and attach the module to the printer with the two screws.
