Zebra ZD410 User Manual

Media
162
Table 4 Types of Media Roll and Fanfold Media
Media Type How It Looks Description
Non-Continuous
Roll Media
Labels have adhesive backing that sticks them to a liner. Tags (or
tickets) are separated by perforations.
Individual labels or tags are tracked and position controlled by one
or more of the following methods:
1. Web media separates labels by gaps, holes, or notches.
2. Black mark media uses pre-printed black marks on the back
side of the media to indicate label separations.
3. Perforated media has perforations that allow the labels or
tags to be separated from each other easily in addition to
position control marks, notches or label gaps.
Non-Continuous
Fanfold Media
Fan-Fold media is folded in a zigzag pattern. Fanfold media can
have the same label separations as non-continuous roll media.
The separations would fall on or near the folds.
This type of media uses black marks or notches to track media
format positioning.
Continuous
Roll Media
Continuous roll media does not have gaps or typically holes,
notches, or black marks either to indicate label separations. This
allows the image to be printed anywhere on the label. A cutter can
be used to cut apart individual labels. With continuous media, use
the transmissive (gap) sensor so the printer can detect when the
media runs out.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
