Zebra ZD410 User Manual

Setup
56
Ethernet (LAN, RJ-45)
The printer requires UTP RJ45 Ethernet cable rated CAT-5 or better.
The printer has a built-in network print server. For more information on configuring your printer to run on a
compatible Ethernet based network, see the Wired and Wireless Print Server users guide. The printer
must be configured to run on your network. The print server on board your printer can be accessed through
the printer’s print server Web pages.
Ethernet Status/Activity Indicators
The Ethernet connector on the printer has two (2) status/activity indicators that are partially visible to
provide interface status at the connector. The printer also has the control panel indicator lights for printer
network operation status, see the Resolving Alerts and Errors for more details.
Ethernet Cable (RJ45
Connector)
LED Status Description
Both OFF No Ethernet link detected
Green 100 Mbps link detected
Green with the Amber flashing 100 Mbps link and Ethernet activity detected
Amber 10 Mbps link detected
Amber with the Green flashing 10 Mbps link and Ethernet activity detected

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
