Zebra ZQ511 User Manual

Using the Printer
21
Charging the Battery
CAUTION: Do not place any charger in locations where liquids or metallic objects may be dropped into the
charging bays.
AC Power Adapter
Figure 11 AC Power Adapter Charging
1. Open the protective cover on the printer to expose the DC input charger jack.
2. Connect the appropriate AC power cord for your location to the adapter and then plug the power cord
into an AC receptacle.
3. Plug the barrel plug from the AC adapter into the charger jack on the printer.
4. The printer powers up and begins charging. The printer can be left on or turned off at this point.
Charging continues in either state.
IMPORTANT: While it is possible to charge the battery when using the printer, charge times will increase
under this condition.
AC Adapter
AC Power Cord
(varies with
geographic location)
DC Input

Zebra ZQ511 Specifications

General

Print Method	Direct Thermal
Resolution	203 dpi
Operating Humidity	10% to 90% non-condensing
Storage Humidity	10% to 90% non-condensing
Maximum Print Width	2.83 inches/72 mm
Maximum Print Speed	5 in./127 mm per second
Media Sensors	Gap, black mark
Connectivity	Bluetooth, USB
Battery	3250 mAh, PowerPrecision+ Li-Ion
Durability	IP54-rated
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Storage Temperature	-40°F to 158°F/-40°C to 70°C
Memory	256 MB Flash; 128 MB RAM
Supported Barcode Types	1D, 2D
Supported Media Types	Labels
Dimensions	2.75 in. H
Power Supply	AC adapter
