Specifications
60
ZPL Font and Bar Code Specifications and Commands
Item Available Options
Standard Fonts 15 bit-mapped fonts; 1 scalable font (CG Trimvirate Bold Condensed)
Downloadable optional bit-mapped and scalable fonts via Net Bridge
software.
International Font Options Zebra offers font kits covering multiple languages including Simplified
and Traditional Chinese, Japanese, Korean, Hebrew/Arabic, and
others.
Linear Bar Codes
2-D Bar Codes
Barcode (CPCL Command)
Aztec (^B0)
Codabar (^BK)
Codablock (^BB)
Code 11 (^B1)
Code 39 (^B3)
Code 49 (B4)
Code 93 (^BA)
Code 128 (^BC)
DataMatrix (^BX)
EAN-8 (^B8)
EAN-13 (^BE)
GS1 DataBar Omnidirectional (^BR)
Industrial 2 of 5 (^BI)
lnterleaved 2 of 5 (^B2)
ISBT-128 (^BC)
LOGMARS (^BL)
Micro-PDF417 (^BF)
MSI (^BM)
PDF-417 (^B7)
Planet Code (^B5)
Plessey (^BP)
Postnet (^BZ)
Standard 2 of 5 (^BJ)
TLC39 (^BT)
UPC/EAN extensions (^BS)
UPC-A (^BU)
UPC-E (^B9)
Maxi Code (^BD)
QR Code (^BQ)
Rotation Angles 0°, 90°, 180°, and 270°

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra ZQ511 and is the answer not in the manual?

Zebra ZQ511 Specifications

General IconGeneral
Print MethodDirect Thermal
Resolution203 dpi
Operating Humidity10% to 90% non-condensing
Storage Humidity10% to 90% non-condensing
Maximum Print Width2.83 inches/72 mm
Maximum Print Speed5 in./127 mm per second
Media SensorsGap, black mark
ConnectivityBluetooth, USB
Battery3250 mAh, PowerPrecision+ Li-Ion
DurabilityIP54-rated
Operating Temperature14°F to 122°F (-10°C to 50°C)
Storage Temperature-40°F to 158°F/-40°C to 70°C
Memory256 MB Flash; 128 MB RAM
Supported Barcode Types1D, 2D
Supported Media TypesLabels
Dimensions2.75 in. H
Power SupplyAC adapter
