Using the Printer

Wearing the Printer

Swivel Belt Clip

The printers have a plastic swivel belt clip included as a standard feature. (It should be noted that printers

with extended capacity battery do not come equipped with a belt clip.) To use: hook the clip over your belt,

and ensure that the clip is securely attached to the belt. The belt clip will pivot to allow you to move freely

while wearing the printer. In order to install or remove the plastic Belt Clip, secure it to the cut-out in the

front of the printer (where shown).

Figure 34 Printer with Belt Clip

Hand Strap

The Hand Strap accessory attaches to the front posts of the printer to provide the user with a convenient

and secure method of carrying the printer. To attach the Hand Strap to the printer:

1. Attach one swivel snap hook to its corresponding post on the front of the printer.

2. Attach the opposite end of the strap to its corresponding post on the front of the printer where shown.

Figure 35 Hand Strap

Clip Here

Strap

Post

Swivel

Snap

Hook
