Zebra ZQ511 User Manual

17
Using the Printer
Preparing the Battery for Use
Installing/Removing Battery and Battery Tape Insulator
IMPORTANT: Batteries are shipped in sleep mode to preserve their maximum capacity while in storage
prior to initial use. The battery needs an initial charging to wake it up before using for the first time. (See
Charging the Battery on page 21.)
Removing the Battery
1. If a belt clip is present on the bottom of the printer, rotate it such that it provides clearance for the
battery.
2. Depress the latch on the battery pack (Figure 5).
Figure 5 Battery Latch

Zebra ZQ511 Specifications

General

Print Method	Direct Thermal
Resolution	203 dpi
Operating Humidity	10% to 90% non-condensing
Storage Humidity	10% to 90% non-condensing
Maximum Print Width	2.83 inches/72 mm
Maximum Print Speed	5 in./127 mm per second
Media Sensors	Gap, black mark
Connectivity	Bluetooth, USB
Battery	3250 mAh, PowerPrecision+ Li-Ion
Durability	IP54-rated
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Storage Temperature	-40°F to 158°F/-40°C to 70°C
Memory	256 MB Flash; 128 MB RAM
Supported Barcode Types	1D, 2D
Supported Media Types	Labels
Dimensions	2.75 in. H
Power Supply	AC adapter
