Specifications

Communication Port

USB

Figure 40 USB Port

Physical, Environmental and Electrical Specifications

Pin # Signal Name

1 VBUS

2 DM(-)

3 DP(+)

4 ID

5 GND

Pin 5

Pin 1

Parameter ZQ521 ZQ511

Weight w/ battery 1.6 lbs. (0.75 kg) 1.35 lbs. (0.61 kg)

Temperature Operating: -20°C to 55°C (-4°F to 131°F) Same

Storage: -30°C to 66°C

(-22°F to 150.8°F)

Same

Charging: 0°C to 40°C

(32°F to 104°F)

Same

Relative Humidity Operating/Storage: 10% to 90% non-condensing Same

Battery Smart Battery (2 or 4 cell) Lithium-Ion, 7.4VDC (nominal);

2.45AHr min.

Same

Intrusion

Protection (IP)

Rating

IP54 (without soft case)

IP65 (with hard case)

Same
