Using the Printer
35
Zebra Android Printer Setup Utility (for Link-OS Printers)
The printers can also be configured using the Zebra Android Printer Setup Utility. This utility can be
downloaded from Google Play to an Android device such as a smartphone or the TC51 or TC56 mobile
handheld computers. The Android mobile device can be paired with the printer via Bluetooth or a USB
cable and users can quickly navigate the app to perform the following tasks.
Figure 25 Setup Utility Main Screen
Shows currently connected printer
Displays current printer status
= all clear
= error present
Quick access to Wizards, Printer Actions
and Files

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra ZQ511 and is the answer not in the manual?

Zebra ZQ511 Specifications

General IconGeneral
Print MethodDirect Thermal
Resolution203 dpi
Operating Humidity10% to 90% non-condensing
Storage Humidity10% to 90% non-condensing
Maximum Print Width2.83 inches/72 mm
Maximum Print Speed5 in./127 mm per second
Media SensorsGap, black mark
ConnectivityBluetooth, USB
Battery3250 mAh, PowerPrecision+ Li-Ion
DurabilityIP54-rated
Operating Temperature14°F to 122°F (-10°C to 50°C)
Storage Temperature-40°F to 158°F/-40°C to 70°C
Memory256 MB Flash; 128 MB RAM
Supported Barcode Types1D, 2D
Supported Media TypesLabels
Dimensions2.75 in. H
Power SupplyAC adapter
