Using the Printer
46
Shoulder Strap
A Shoulder Strap accessory is also offered to provide another option for comfortably carrying the ZQ511
and ZQ521 printers. Similar to the Hand Strap, the shoulder strap attaches to the two strap posts on the
front of the printer via rugged swivel snap hooks as shown in Figure 36. The strap is easily adjustable up to
56 inches from end to end.
Figure 36 Shoulder Strap
Soft Case
The printers have an environmental Soft Case option that helps protect the printer, while also allowing the
user to carry it from their belt. The paper path is left open to maintain printing capability and the controls
are visible and accessible while in the case. D-Ring connectors allow for attachment to the shoulder strap
option.
Figure 37 Soft Case
Adjustable
Clip
Swivel Snap
Hooks

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra ZQ511 and is the answer not in the manual?

Zebra ZQ511 Specifications

General IconGeneral
Print MethodDirect Thermal
Resolution203 dpi
Operating Humidity10% to 90% non-condensing
Storage Humidity10% to 90% non-condensing
Maximum Print Width2.83 inches/72 mm
Maximum Print Speed5 in./127 mm per second
Media SensorsGap, black mark
ConnectivityBluetooth, USB
Battery3250 mAh, PowerPrecision+ Li-Ion
DurabilityIP54-rated
Operating Temperature14°F to 122°F (-10°C to 50°C)
Storage Temperature-40°F to 158°F/-40°C to 70°C
Memory256 MB Flash; 128 MB RAM
Supported Barcode Types1D, 2D
Supported Media TypesLabels
Dimensions2.75 in. H
Power SupplyAC adapter
