Zebra ZQ511 User Manual

Printer Overview
15
Printer Features
Figure 2 Overview of Features (ZQ511 Shown).
NOTE: Scanning the QR code with a mobile device will provide printer-specific information at
www.zebra.com/ZQ511-info
and www.zebra.com/ZQ521-info.
NOTE: Tapping the Zebra Print Touch ™ icon with a Near Field Communication (NFC) enabled mobile
device will provide instant access to printer-specific information. For more information about NFC and
Zebra products, go to http://www.zebra.com/nfc
. Bluetooth pairing applications via NFC is also possible.
Please see Zebra Multi-platform SDK for more information.
1
2
3
4
5
6
7
8
1
9
4
10
1 Tear bar (Not present in Linerless. Scraper
present instead.)
6 Latch release button
2 Platen roller 7 DC input
3 Black bar sensor 8 USB port
4 Media support disks 9 Gap sensor
5 Printhead 10 Media cover

Zebra ZQ511 Specifications

General

Print Method	Direct Thermal
Resolution	203 dpi
Operating Humidity	10% to 90% non-condensing
Storage Humidity	10% to 90% non-condensing
Maximum Print Width	2.83 inches/72 mm
Maximum Print Speed	5 in./127 mm per second
Media Sensors	Gap, black mark
Connectivity	Bluetooth, USB
Battery	3250 mAh, PowerPrecision+ Li-Ion
Durability	IP54-rated
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Storage Temperature	-40°F to 158°F/-40°C to 70°C
Memory	256 MB Flash; 128 MB RAM
Supported Barcode Types	1D, 2D
Supported Media Types	Labels
Dimensions	2.75 in. H
Power Supply	AC adapter
