Carl Zeiss Axiotech and Axiotech
vario
IV B 40-020 e 06/99
Page
2 START-UP ...................................................................................................................... 2-3
2.1 Unpacking the microscope .............................................................................................. 2-3
2.1.1 Axiotech 30 and Axiotech 100......................................................................................... 2-3
2.1.2 Axiotech
vario
100 ............................................................................................................... 2-3
2.2 Setting up the microscope............................................................................................... 2-4
2.2.1 Axiotech
vario
- Attaching the microscope body to column X95 ............................................ 2-4
2.3 Screw in objectives ..........................................................................................................2-5
2.4 Attachment or change of binocular tubes and intermediate tubes .................................... 2-5
2.4.1 Attachment of binocular tubes ........................................................................................ 2-5
2.4.2 Attachment of intermediate tube for image projection..................................................... 2-6
2.4.3 Attachment of Optovar intermediate tube ....................................................................... 2-7
2.5 Insertion of eyepieces ...................................................................................................... 2-8
2.5.1 Insertion of the eyepiece reticle........................................................................................ 2-9
2.5.2 Compensation of ametropia when eyepiece reticles are used ......................................... 2-10
2.6 Setting of eyepiece (interpupillary) distance and viewing height...................................... 2-10
2.7 Attachment of condenser.............................................................................................. 2-11
2.8 Attachment, change and centering of the microscope stage........................................... 2-12
2.8.1 Axiotech 30 and Axiotech 100 with stage carrier A ........................................................ 2-12
2.8.2 Axiotech 30 and Axiotech 100 with stage carrier D and adapter..................................... 2-13
2.8.3 Axiotech
vario
100 with stage carrier H = 140 mm ............................................................. 2-14
2.8.4 Centering of Pol rotary stage......................................................................................... 2-15
2.9 Change of filters ........................................................................................................... 2-16
2.9.1 Equip the filter slider with filters and push it in the beam path........................................ 2-16
2.9.2 Change filters of reflector slider..................................................................................... 2-16
2.10 Setting of reflected-light luminous-field diaphragm ........................................................ 2-18
2.10.1 Axiotech 30 .................................................................................................................. 2-18
2.10.2 Axiotech 100 and Axiotech
vario
100 ................................................................................. 2-18
2.11 Connection to the line and switching the instruments on and off ................................... 2-19
2.11.1 Connection of Axiotech 30............................................................................................ 2-19
2.11.2 Connection of Axiotech 100.......................................................................................... 2-20
2.11.3 Connection of Axiotech
vario
100 ...................................................................................... 2-21
2.12 Reflected-light illumination equipment........................................................................... 2-22
2.12.1 Change of 6 V 30 W halogen lamp (Axiotech 30)........................................................... 2-22
2.12.2 Attachment of 12 V 100 W halogen illuminator, adjustment and change
of 12 V 100 W halogen lamp (Axiotech 100 and Axiotech
vario
100) .................................. 2-23
2.12.3 Attachment and connection of N XBO 75 Xenon short-arc illuminator............................ 2-26
2.12.4 Attachment and connection of HBO 50 mercury-pressure short-arc illuminator............... 2-26
2.13 Transmitted-light illumination equipment....................................................................... 2-27
2.13.1 Change of 6 V 30 W halogen lamp in the stand base (Axiotech 30 and Axiotech 100).... 2-27
2.13.2 Connecting the 6 V 30 W halogen illuminator to the line (Axiotech 30 and Axiotech 100)2-28
2.13.3 Change of 6 V 30 W halogen lamp (Axiotech
vario
100)..................................................... 2-29
2.13.4 Connection of power supply for 6 V 30 W halogen illuminator (Axiotech
vario
100) ............ 2-30
