ZETRON Model 25 - Reach Code Plan; Five;Six-Tone Frequencies and Timings

Index
124 025-9567E
Reach Code Plan
Pager
Capcode
Indiv. Call
Tone Groups
0yx Z5+Z3
1xy Z1+Z2
2yx Z2+Z1
3xy Z3+Z4
4yx Z4+Z3
5xy Z1+Z4
6yx Z4+Z1
7xy Z1+Z5
8yx Z5+Z1
9xy Z3+Z5
Please note that the ones/tens digit encoding, shown by “x” and “y”, reverses position for
each 100 pager block. In GE/Motorola plans, first tone is always tens digit, and second tone
is ones digit.
For a REACH group call, 0xx group is not present. Instead, ten group calls are accessible
using pager numbers 000,011,022, ... 099, that generate the ten group call tones from tone
group Z1. The group calls activate 1st tone Z1 pagers (cap codes 1xx, 5xx, and 7xx).
Five/Six-Tone Frequencies and Timings
Tone Number EIA CCIR ZVEI
0 600 1981 2400
1 741 1124 1060
2 882 1197 1160
3 1023 1275 1270
4 1164 1358 1400
5 1305 1446 1530
6 1446 1540 1670
7 1587 1640 1830
8 1728 1747 2000
9 1869 1860 2200
2nd Address X 2010 2247 970
Repeat R 459 2110 2600
Timing
Preamble 673 673 673
Gap 65 65 65
Tone 33 40 100
X Tone 65 40 100
Note: All tone frequencies are in hertz and all tone timings are in milliseconds.
