Programming - Front Panel
025-9567E 71
9 DTMF 3 sec. ON 5 sec. OFF
A DTMF 0.15 sec. ON 0.15 sec. OFF
Question “F” - Format Assignment
Once you have selected a leading digit to work on, the unit will now display:
Here, a format will be assigned to the leading digit selected in “Question b”. The Model 25
will allow only those formats ordered to be assigned to leading digits. If entry of a
nonresident format is selected the Model 25 will again display the “Question F” prompt and
await the entry of a valid format number.
Note: The Two-Tone Format (format number 2) is a standard format supplied with
every Model 25. Each of the other formats may be individually ordered from
Zetron as an option.
Once the “Question F:” digits have been entered, the Model 25 will either load the
information to its memory and return to the first question in this section (Question bo:)
completing the question loop, or prompt for additional information. The additional
information is required to inform the encoder of information unique to each format. The
following list shows the digits assigned to each paging format.
0 = Custom Calls (no additional questions, “Return to Question bo:”)
1 = Clear the Leading Digit (no additional questions, “Return to Question bo:”)
2 = Two-Tone (1000-Call)
3 = Motorola (2+2) Quick Call 1
4 = 5/6-Tone Sequential (Motorola)
5 = DTMF
6 = 2805/1500 Hertz Rotary Dial
7 = Alert Tone Format
8 = Digitone
9 = Golay Sequential
What follows is a detailed description of the remaining questions for those formats that
require additional information to be fully configured.
Two-tone
If you entered a “2” in response to “Question F” (page 71), the unit will now display:
