Programming - Serial Port
114 025-9567E
INSTANT CALL BUTTON SELECT (0000-0358)
PC1>0010
1-ENTER STACK
PC1;0010>9101
9101'
PC1;0010>1432
1432'
PC1;0010>1555
1555'
0010 , STACK PROGRAMMED
Either way, once the encoder stores the stack and returns to the start of the instant call
question loop, you can either enter the loop again to program another instant call key or
simply press ENTER/RETURN on the PC keyboard to return to the idle state.
GENERAL AND SEND BUTTON SETUP
This section of programming configures those features that control the general operation of
the encoder and allows you to define the operation of the four SEND buttons on the front
panel of Model 25s that have displays and keypads.
Entering an “A” at the top menu brings up the opening prompt for the general and SEND
button setup.
A - SEND BUTTON SETUP
1-CHANGE SETTINGS
2-PRINT ALL SETTINGS
3-PRINT SELECTED SETTINGS
PA>1
CHANGE ALL SETTINGS!
The first prompt asks you to indicate whether you will be doing general programming or
working on an individual SEND button. A “0” selects general programming and entering a
“1” through “4” selects the
SEND button with the same number.
GENERAL OR SEND BUTTON SETUP(0-4)
PA1>0
General Setup
If you entered a “0” to the last prompt the next one will be for setting the operating mode of
the channel select relays. Enter a single-digit response (0 or 1) to indicate which mode the
eight select relays should operate in; Direct or Momentary. The default setting is “0” for
Direct mode.
