Programming - Front Panel
70 025-9567E
To select a character for use as a leading digit, enter a single character. The valid choices are:
1 through 9, A, B, C, and D. The encoder will proceed to question âFâ to allow you to select
a paging format to assign to this leading digit. This question is very important. The operation
of the encoder is based on the configuration of the leading digit. We will use the following
example to demonstrate its purpose.
Assume your Model 25 was ordered with Motorola Two-Tone, Custom Calls, DTMF, and
Motorola (2+2). Both the Motorola Two-Tone and Custom Calls require a 3-digit entry. The
DTMF and Motorola (2+2) formats require a 4-digit entry. As seen in Table 20, there is no
way to determine which calls belong to which formats. However, when a leading digit is
attached to the beginning of each call, it is very easy to associate each call with a format. The
leading digit must be either 1 through 9 or A, B, C, or D. The leading digit used for each
format does not matter but each character may only be used once, however the same paging
format may be assigned to multiple leading digits. This is very useful for example if your
system contains DTMF decoders that require multiple timings. The DTMF format could be
assigned to as many leading digits as you have timings each leading digit would be
configured to contain a different timing as shown in Table 21.
Table 20. Encoder without/with Leading Digits
Leading Digits Formats Calls Format Used
? Motorola Two-Tone 1234 ?
? Custom Calls 325 ?
? DTMF 8945 ?
? Motorola (2+2) 475 ?
350 ?
857 ?
6934 ?
Leading Digits Formats Calls Format Used
1 Motorola Two-Tone 31234 DTMF
2 Custom Calls 1325 Motorola Two-Tone
3 DTMF 48945 Motorola (2+2)
4 Motorola (2+2) 2475 Custom Calls
1350 Motorola Two-Tone
2857 Custom Calls
36934 DTMF
Table 21 demonstrates how multiple leading digits may be used to provide the same format
with different settings.
Table 21. Supporting Multiple Timings for a Single Format
Leading Digit Format Timing
7 DTMF 1 sec. ON 2 sec. OFF
8 DTMF 0.5 sec. ON 0.5 sec. OFF
