Operation
025-9567E 15
Each Instant Call key represents a call stack via a four-digit position dependent number. The
number generated by each key is in the form “0prc”. The meaning of each digit is:
“0” leading digit used to access the stack block
“
p” panel number on which the key resides
“r” row number of the key
“
c” column number of the key
The number for the Instant Call panel inside the encoder enclosure is “0” for the half-sized
panel of the encoder with keypad (901-9019) and “1” for the full sized panel of the encoder
without keypad (901-9022). The panel number of the Auxiliary Instant Call panels depend on
the placement of the address jumper at time of installation. The possible panel numbers for
the Auxiliary panels (901-9020) are “1”, “2”, and “3”.
Rows on a panel are numbered from 0 to 5 with 0 being the top-most row and 5 being the
bottom-most row. Columns on full sized panels are numbered from 0 to 9. Columns on half
sized panels are numbered from 0 to 4. The left-most column is always column 0.
The lower right hand key (0054 or 0p59) of each panel is reserved as the CLEAR key for that
panel. If the review-before-send option is enabled then the lower left key (0p50) is reserved
as the SEND QUEUE key. The reserved keys generate no position number when pressed. A
map of the Instant Call key numbers is shown in Figure 3.
0000 0001 0002 0003 0004
0010
0011 0012 0013 0014
0020
0030
0040
0021
0031
0041
0050
0051
0022
0032
0042
0052
0023
0033
0043
0053
0024
0034
0044
0054
0p00 0p01 0p02 0p03 0p04
0p10
0p11 0p12 0p13 0p14
0p20
0p30
0p40
0p21
0p31
0p41
0p50
0p51
0p22
0p32
0p42
0p52
0p23
0p33
0p43
0p53
0p24
0p34
0p44
0p54
0p05 0p06 0p07 0p08 0p09
0p15
0p16 0p17 0p18 0p19
0p25
0p35
0p45
0p26
0p36
0p46
0p55
0p56
0p27
0p37
0p47
0p57
0p28
0p38
0p48
0p58
0p29
0p39
0p49
0p59
Half Size Panel
Full Size Panel
(p = 1, 2, or 3)
Clear
Clear
Send
Queue
Send
Queue
Figure 3. Key Numbering Scheme for Half and Full Sized Panels
