Operation
26 025-9567E
4. Is last call a custom call with alert?
:Yes - Print alert
Generate 3 seconds of alert
5. Open audio relay
Display time (if time clock installed)
Print bar
Issue one beep
6. Wait one second for another Instant Call
Instant Call received?
:Yes - Process call again at step 1.
7. Open PTT relay
Open control relays.
Momentary Select
1. Is PTT still closed and are the last used control relays same as the desired control
relays?
:Yes - Skip remaining steps here
2. Open PTT relay
Open control relays
Wait 150 milliseconds
Close programmed control relays
Wait 150 milliseconds
Open control relays
SAMPLE CHANNEL BUSY
3. Is channel busy used and has it been busy for over 30 seconds?
:Yes - Skip remaining steps here
4. Close PTT relay (if verify mode off)
Wait the programmed key-up delay
Close the audio relay
