Programming - Front Panel
025-9567E 77
“Question 2” allows you to select one of the standard 5/6-tone tone groups EIA, CCIR, or
ZVEI to be used for this leading digit. If more than one tone group is required, then more
than one leading digit must be used, one for each tone group. The EIA tone group is the one
most commonly used in the USA.
The encoder is looking for a single digit entry (0 to 2). The valid responses are:
0 = EIA
1 = CCIR
2 = ZVEI
Question 3 - Address Type
Most 5/6-tone pagers are capable of the dual address function, however the encoder is the
device that determines whether the dual function is used. The second “address” must be sent
by the encoder in order for the pagers to react to it. The Model 25 is capable of single or dual
address operation. The encoder is looking for a single-digit response (0 to 1) for this
question. The valid responses are:
0 = Single Address operation
1 = Dual Address operation
Saving the Changes
Once the single-digit response for “Question 3” has been entered, the Model 25 will
immediately begin to load all changes made in this section to memory to be used until new
changes are made. During the time that the Model 25 is loading this information to memory,
the display will appear as shown here.
CAUTION
Do not remove power or press the RESET button while the Model 25 is loading the
memory, otherwise incorrect information could be loaded requiring reprogramming.
Once the Model 25 completes the loading procedure, it will return to the first question in the
two-tone programming section, “Question “bo”” on page 69. You may select another leading
digit to format or press
RESET to exit the programming mode back to the idle state.
