ZiLOG Z8 Series User Manual

Z8
®
CPU
User Manual
UM001604-0108 Power-Down Modes
110
Power-Down Modes
In addition to the standard RUN mode, the Z8
®
CPU supports two Power-Down modes to
minimize device current consumption. The two modes supported are HALT and STOP.
Halt Mode Operation
HALT mode suspends instruction execution and turns off the internal CPU clock. The on-
chip oscillator circuit remains active so the internal clock continues to run and is applied to
the Counter/Timer(s) and interrupt logic.
To enter HALT mode, it is necessary to first flush the instruction pipeline to avoid sus-
pending execution in mid-instruction. To do this, the application program must execute a
NOP instruction (opcode =
FFh) immediately before the HALT instruction (opcode 7Fh),
that is:
FF NOP ;clear the instruction pipeline
7F HALT ;enter HALT mode
HALT mode is exited by interrupts, either externally or internally generated. Upon com-
pletion of the interrupt service routine, the user program continues from the instruction
after HALT.
HALT mode may also be exited via a POR/RESET activation or a Watch–Dog Timer
(WDT) time-out. (See the product data sheet for WDT availability). In this case, program
execution restarts at the reset restart address
000Ch.
To further reduce power consumption in HALT mode, some Z8 family devices allow
dynamic internal clock scaling. Clock scaling may be accomplished on the fly by repro-
gramming bit 0 and/or bit1 of the Stop Mode Recovery register. See Figure 103 on page
112.
Internal clock scaling directly affects Counter/Timer operation—adjustment of the pres-
caler and downcounter values may be required. To determine the actual HALT mode cur-
rent (I
CC1
) value for the various optional modes available, see the related Z8 device’s
product specification.
Stop Mode Operation
STOP mode provides the lowest possible device standby current. This instruction turns
OFF the on-chip oscillator and internal system clock.
To enter STOP mode, it is necessary to first flush the instruction pipeline to avoid sus-
pending execution in mid-instruction. To do this, the application program must execute a
Note:
