ZiLOG Z8 Series User Manual

Z8
®
CPU
User Manual
UM001604-0108 Z8
®
CPU Product Overview
3
Product Development Support
The Z8
®
MCU product line is fully supported with a range of cross assemblers, C compil-
ers, ICEBOX emulators, single and gang OTP/EPROM programmers, and software simu-
lators.
The
Z86CCP01ZEM low-cost Z8 CCP real-time emulator/programmer kit is designed
specifically to support all the products outlined in Table 1 on page 3.
The Z86CCP01ZEM kit includes:
• Z8 CCP evaluation board
• Z8 CCP power cable
• Zilog Developer Studio (ZDS) CD-ROM, Including Windows-Based GUI Host Soft-
ware
• 1999 Zilog Technical Library
• Z8 CCP User Manual
Table 1. Zilog General-Purpose Microcontroller Product Family
Product
ROM/
RAM I/O T/C AN INT WDT POR V
BO
RC
Speed
(MHz)
Pin
Count
Z86C03 512/60 14 1 2 6 F Y Y Y 8 18
Z86E03 512/60 14 1 2 6 F Y N Y 8 18
Z86C04 1K/124 14 2 2 6 F Y Y Y 8 18
Z86E04 1K/124 14 2 2 6 F Y N Y 8 18
Z86C06 1K/124 14 2 2 6 P Y Y Y 12 18
Z86E06 1K/124 14 2 2 6 P Y N Y 12 18
Z86C08 2K/124 14 2 2 6 F Y Y Y 12 18
Z86E08 2K/124 14 2 2 6 F Y N Y 12 18
Z86C30 4K/236 24 2 2 6 P Y Y Y 12 28
Z86E30 4K/236 24 2 2 6 P Y N Y 12 28
Z86C31 2K/124 24 2 2 6 P Y Y Y 8 28
Z86E31 2K/124 24 2 2 6 P Y N Y 8 28
Z86C40 4K/236 32 2 2 6 P Y Y Y 16 40/44
Z86E40 4K/236 32 2 2 6 P Y N Y 16 40/44
Note: Z86Cxx signify ROM devices; 86xx signify EPROM devices; F = fixed; P = programmable.
