Z8
®
CPU
User Manual
UM001604-0108 Instruction Description
183
Increment
Instruction Format
Operation
dst ← dst + 1
The contents of the destination operand are incremented by one.
Address modes R or IR can be used to specify a 4-bit Working Register. In this format, the
destination Working Register operand is specified by adding
1110b (Eh) to the high nibble
of the operand. For example, if Working Register R12 (CH) is the destination operand, then
ECh is used as the destination operand in the Op Code.
Example 1
If Working Register R10 contains 2Ah, the statement:
INC R10
Op Code: AE
leaves the value 2Bh in Working Register R10. The Z, V, and S Flags are cleared.
Example 2
If Register B3h contains CBh, the statement:
INC B3h
Op Code: 20 B3
leaves the value CCh in Register CBh. The S Flag is set, and the Z and V Flags are cleared.
Cycles
OPC
(Hex)
Address Mode
dst
dst OPC 6 rE r
OPC dst
620 R
621 IR
Flag Description
C Unaffected
Z Set if the result is zero; cleared otherwise.
S Set if the result of bit 7 is set (negative); cleared otherwise.
V Set if arithmetic overflow occurs; cleared otherwise.
D Unaffected
H Unaffected
Edst
Note:
