CPU

User Manual

UM001604-0108 Instruction Description

224

Example 1

If the contents of Working Register R6 are 31h (00110001B), the statement:

RR R6

Op Code: E0 E6

leaves the value 98h (10011000) in Working Register R6. The C, V, and S Flags are set,

and the Z Flag is cleared.

Example 2

If the contents of Register C6 are 31h and the contents of Register 31h are 7Eh

(

01111110b), the statement:

RR @C6

Op Code: E1 C6

leaves the value 4Fh (00111111) in Register 31h. The C, Z, V, and S Flags are cleared.

Edst
