Z8
®
CPU
User Manual
UM001604-0108 Input/Output Ports
59
Figure 46. Port 3 Configuration with Comparator
PIN
P37
0 P34, P37 Standard Output
1 P34, P37 Comparator Output
D0
P37 OUT
PCON
P32
REF (P33)
+
-
PIN
P34
P37 OUT
P32
REF (P33)
+
-
