Component number Description
JP1001-JP1004 JP1001-1004
(230V: JP1001/1002; 110V: JP1003/1004)
ST1001 Mains voltage connection (PhySys Edition SD/ VacoP)
SI1001 Pump fuse (1,25AT)
ST1203 Stimulating current connection (PhySys Edition SD/ Vacoboard)
ST1204 Stimulating current connection (VacoP mainboard/ suction electrodes)
ST1201 Connection of the VacoP user cable
( ADC_Press, Levelsens, Pump, Valve, GND, %V, 12V EXT und 5V 0,5%)
ST1202 Connection of the water level sensor cable
ST1502 Connection of the valve cable
BU1401 Connection of the pump cable
