8.3.1.9. Replacement of power inlet element
¾ Opening the rear part of housing (see 8.3.1.1)
¾ Now slide the power inlet out of the housing wall and disconnect the cable from the mains switch and the
PE-conductor from the power supply board.
¾ After replacing the power inlet element, insert it to their position at the housing and connect the new cable
to the mains switch and power supply board
¾ Mount the rear part of housing
Figure 25
