9. Technical Data
For more information see the user manual
Operating voltage PhySys Edition SD 100-240V~, 50Hz/60Hz 220V~/50Hz
Operating voltage VacoP
100-120V/ 50Hz/ 60Hz or 230-240V/ 50Hz/ 60Hz
Power consumption PhySys Edition SD max. 200 VA
Power consumption VacoP max. 35 VA
Fuse PhySys Edition SD 2x 2AT
Fuse VacoP
2x 0,2AT (100-120V device)
2x 0,4AT (230-240V device)
Protection class PhySys Edition SD IEC 601-1, Class 1, Type BF
Protection class VacoP IEC 601-1, Class 2, Type BF
MDD / MPG PhySys Edition SD Class IIa
MDD / MPG VacoP Class IIa
Housing dimensions
PhySys Edition SD HxWxD (300mmx350mmx200mm)
VacoP 322mm x 234mm x 260mm
Weight
PhySys Edition SD 3,8 Kg
VacoP 2,2 Kg
Transport The device should only be shipped in its original packaging
Ambient temperature in operation:
Temperature: +10°C to +40° C, humidity level from 30 % to 90 %
and 700 hPa – 1060 hPa
Storage
Temperature: 0°C to +70° C, humidity level from 10 % to 100 % and
500 hPa – 1060 hPa
