6.2.2. Overview Vaco device
6.2.2.1. VacoP User connection
Name Note
AMP connector
Pin 1 12V EXT
Pin 2 Vaco_Fluid_Level
Pin 3 VACO_Pump
Pin 4 Cathode
Pin 5 Anode
Pin 6 GND
Pin 7 VACO_Valve_ON
Pin 8 Pressure_Vaco
Pin 9 SHIELD
Pin 10 -
Pin 11 12_CTRL
Pin 12 VACO Detection
Pin 13 5V 0,5%
Pin 14 Cathode Float.
Pin 15 Anode Float.
6.2.2.2. Power supply connection (ST1001)
Name Note
1 N ( blue)
2 L (brown)
6.2.2.3. Jumper (JP1001-JP1004)
Name Note
JP1001 and JP1002 For 230V power supply
JP1003 and JP1004 For 115V power supply
6.2.2.4. VacoP User connection (ST1201)
Name Note
1 Pressure_Vaco
2 Vaco_Fluid_Level
3 VACO_Pump
4 VACO_Valve_ON
5 GND
6 12_CTRL
7 12V EXT
8 5V 0,5%
6.2.2.5. Stimulating current connection (ST1204) (PhySys Edition SD/ Vacoboard)
Name Note
1 Anode Float.
2 Cathode float.
3 Anode
4 Cathode
