Zimmer SD Edition PhySys - Page 27

PhySys Edition SD Service Manual
Rev. B
20.08.2013
Page 27/52
Service Manual PhySysSD_RevB_20.08.2013.do
c
¾ Update DSP1
¾ Update DSP2
¾ Update Main CPU
Figure 17
¾ After installing the PhySys Edition SD start automatically and it appears the message:
“Firmware update done”
1
2
3
