Chapter 4 Network Status
NR2301 User’s Guide
39
The following table describes the labels in this screen.
Table 10 NETWORK STATUS
LABEL DESCRIPTION
Online User This field displays the number of clients that are currently connected to the NR2301. Click
this to go to the USER LIST > Online Users screen to view information of the clients and
configure them.
See Section 5.2 on page 40 for more information.
Current SIM Volume This sections shows the current SIM card usage statistics. Click this to go the APP MODULE >
Statistics screen.
Upload This field displays the number of transmitted packets on the SIM card for the current
connection session.
Download This field displays the number of received packets on the SIM card for the current
connection session.
Total This field displays the total number of transmitted and received packets on the SIM card for
the current connection session.
Duration This field displays the duration of the current connection session
Download Rate This field displays the NR2301's traffic download rate.
Upload Rate This field displays the NR2301's traffic upload rate.
CPU Occupancy This field displays what percentage of the NR2301’s processing ability is currently used.
When this percentage is close to 100%, the NR2301 is running at full load, and the
throughput is not going to improve anymore.
