Chapter 1 Getting To Know Your ZyXEL Device
P-662H/HW-D Series User’s Guide
42
Refer to the Quick Start Guide for information on hardware connections.
WLAN (P-
662HW only)
Green On The ZyXEL Device is ready, but is not sending/receiving data
through the wireless LAN.
Blinking The ZyXEL Device is sending/receiving data through the
wireless LAN.
None Off The wireless LAN is not ready or has failed.
DSL/ACT Green On The ZyXEL Device has a successful DSL connection.
Blinking The DSL is attempting to synchronize with the ZyXEL
Device.
Off The system is not receiving power or there is no DSL
connection.
INTERNET Green On The ZyXEL Device is connected with no traffic detected.
Blinking The ZyXEL Device is sending/receiving data.
Red On The ZyXEL Device failed to authenticate.
Off The DSL line is down.
CON/AUX Green On The CON/AUX switch is set to CON, the CON/AUX port is
connected to a management computer and someone is
logged into the ZyXEL Device.
Amber On The CON/AUX switch is set to AUX and the CON/AUX port
has an Internet connection through a dial-up modem.
Blinking The CON/AUX switch is set to AUX and the CON/AUX port
is sending or receiving data through a dial-up modem or
ISDN TA.
Off The CON/AUX link is not ready, or has failed.
Table 1 Front Panel LEDs (continued)
LED COLOR STATUS DESCRIPTION
