3. On the Main Pad Parameters page, there are
three buttons below the measure and beat
count. The left most button is the grid icon and
pad selector. Touch this icon to change which
pad you are editing. The pink square indicates
which pad you are currently editing. The
second button is the WAV le name. Touch it to
select a dierent WAV le. The third button is
the Play button. Touch it to trigger playback of
the pad. The playback functionality will depend
on the other parameter settings. The WAV le
is playing when this button is highlighted blue.
When this square is lled in white, the pad is
queued up to begin when the appropriate
quantization break is reached.
4. Some of the pad parameters are the same for
all Pad Modes, while others vary by mode. .
Here are the parameters that are the same for
all Pad Modes:
Copyright 1010music LLC 2020
Page 22 of 88
Bitbox Micro User Manual 1.0.7
Pad Parameters Screen
Parameter Description Range of Values Mod
Target?
Level
Adjusts the loudness level of the pad -96dB to +12dB Yes
Filter
Applies either a high pass or low pass
lter to this pad.
-100% to +100%
Negative values apply a low pass lter.
Positive values apply a high pass lter.
Yes
Pitch
Adjusts the pitch of the pad up or
down
-24.0 to +24.0 semitones Yes
Launch
Mode
This controls how a note trigger
aects the playback of a pad.
Trigger: Activate the Pad by touching the
pad or through MIDI note on. Bitbox
micro will start playback of the WAV le
and play through to the end.
Gate: Begin the WAV le playback in the
same manner as Trigger mode. But in
Gate mode, playback will stop when you
release the touch or the MIDI note is
released.
Toggle: Begin the WAV le playback in
the same manner as Trigger mode.
When another trigger event happens, the
playback will stop.
No
Output
The output of this pad is sent to the
output or outputs selected here. It will
always also be sent to the Master
Outs on Jacks 7 and 8.
Out1/2, Out 3/4, Out 5/6, Out 1, Out 2,
Out 3, Out 4, Out 5, Out 6
No
