3. Connect a MIDI Device to bitbox micro and set the device to use the channel
assigned to MIDI Keys.
4. Go to the Pads screen and select a pad to play via MIDI. Play notes on the
MIDI Device and you will see and hear the currently selected pad respond to
the MIDI notes. Select a dierent pad and play notes on the MIDI Device and
you will see and hear the new pad respond.
To Congure MIDI modulation for a parameter using named MIDI sources:
1. From the Pads screen, touch the pad you want to modulate.
2. Push the right arrow button to go to the Pad Parameters screen. Set the MIDI
parameter to a MIDI channel to be used to modulate this pad.
3. Scroll to select the parameter you want to modulate.
4. Push the right arrow button to display the Modulation Parameters screen.
5. Use the control knobs to select a value for the Source parameter for each
modulation source you want to use. This parameter species which signal will
be used to control this parameter. Available values are:
None – no modulation source will be used.
Trig - The pad is triggered. This is only useful with the slice
sequencer.
VEL – MIDI Velocity or the Velocity slider on the Pads screen. This
is note specic.
PTCH – MIDI pitch bend signal
MODW – MIDI Mod Wheel
MVOL – MIDI Volume
MPAN – MIDI Pan
Notes:
► If you have the same channel assigned to both a specic pad and to the MIDI
Keys setting, the assigned pad and the currently selected will both respond to
the MIDI input.
Page 73 of 88
Copyright 1010music LLC 2020
