Bitbox Micro User Manual 1.0.7
6. At the top of the Load and Record screen, touch the 1x button next to the grid
icon at the top left of the screen. The Mode Selector menu will drop down.
Touch Multi. You are now in Multi or Mx mode. The list of recording
parameters is dierent to support this mode.
7. Select values for the following parameters to congure your recording
session:
WAV File Load and
Record Screen -
Mode Selector
WAV File Load and
Record Screen -
Mx Mode
Recording
Parameter
Description Range of Values
Rec Input
Choose which input to record.
You can choose one or both audio inputs,
or you can choose to resample the signal
being sent to outputs 1 and 2.
In 1/2, In 1, In2, Resam
Gain
The VU meters represent the level of the
signal to be recorded. You can adjust the
gain to get the desired level and avoid
clipping.
-96.0 dB to + 20.0 dB
Filename
The name of the folder that will store the
multi-sample bank recordings. It will also
be used as a prex for the individual le
names.
Push the right arrow button to open the le
naming screen. Turn the bottom knob to
choose a letter. Turn the top knob to move the
cursor position.
Start Note
The note that will be sent out as a trigger
to record the rst WAV le.
C#-1 (1) through G9 (127)
End Note
The note that will be sent out to trigger
the last WAV le that will be recorded.
C#-1 (1) through G9 (127)
Sample
Every
How many semi-tones or notes are
between each WAV le recorded. Set to 1
to record a WAV le for each note. Set to
12 to record one note per octave.
1 through 16
