PANEL PROGRAMMING
When programming wireless and wired zones, as well as keyfobs
and keypads, installers are required to choose options for a variety of
settings. This topic describes each setting and its available options.
Sensor Programming Reference
Required for all wired and wireless zones.
Sensor Type Description
(00) Unused This is the setting for unused sensor
numbers that do not have a sensor
programmed into them. No system action
occurs at any time from this sensor type.
(01) Exit/Entry 1 This sensor type is reserved for doors
that are used for exit and entry of the
protected premises. When the system
is armed in the Stay or Away mode, the
exit delay timer starts. There is an exit
delay regardless of whether the system is
armed in Stay or Away mode. When the
exit delay timer expires, the system is fully
armed.
With the system fully armed, when this
type of sensor is triggered, the Entry
Delay 1 timer starts. The system must be
disarmed before the Entry Delay 1 timer
expires, or an alarm will occur.
If the entry delay timer is turned OFF
during arming, the exit/entry delay
sensors will act as non-delayed instant
sensors at the end of the exit delay.
(02) Exit/Entry 2 This sensor type operates the same as
the Exit/Entry 1 sensor type except that it
starts the Entry Delay 2 timer. This provides
a method of having a longer entry delay
on certain openings, such as a garage
door, to provide the end user more time to
disarm the system.
(03) Perimeter This sensor type is for perimeter doors
and windows that will not be used to
enter or exit the protected premises while
the system is armed. An instant alarm
will occur when this type of sensor is
triggered with the system armed in either
the Stay or Away mode.
(04) Interior
Follower
This sensor type is for interior sensors,
such as motion detectors, interior doors,
and other sensors that detect human
presence inside the protected premises.
This type of sensor is called a “follower”
due to its action when the system is
armed. in the Away mode. After the exit
delay expires and the system is armed,
if an interior follower sensor is triggered,
an instant alarm will occur. If an exit/entry
delay sensor is triggered rst, the interior
follower sensor will also be delayed.
Interior follower sensors are always
bypassed and not active when the system
is armed in Stay mode. This allows
the premises to be occupied while still
protecting the perimeter.
(05) Day Zone This sensor type is the same as a
perimeter zone, except that when the
system is disarmed, a violation displays
a trouble alert on the Console’s display.
This type of sensor is commonly used
to protect sensitive areas that require
notication and possibly a Central Station
trouble report, but not an alarm when the
system is disarmed.
(06) 24-Hour
Silent Alarm
This sensor type is active independent of
the system arming status. The code for
silent panic is sent to the Central Station,
but for safety, there are no visual or
audible indications locally that this sensor
type has been triggered.
(07) 24-Hour
Audible Alarm
This sensor type is continuously armed
24-hours-a-day. A sensor programmed
to this type will trigger a local alarm and
the bell output regardless of the mode the
system is in. This sensor type is typically
used for an audible panic alarm.
(08) 24-Hour
Auxiliary Alarm
This sensor type is continuously armed
24-hour-a-day. A sensor programmed to
this type will trigger an alarm regardless of
the mode the system is in. The bell output
will not activate, but the local sounder will
continue until it is acknowledged at the
Control Panel. This sensor type is typically
used for a monitoring device, such as a
ood or temperature sensor. There is no
time out for the internal sounds; it will
continue until a user code is entered.
