Installation Guide for the 2GIG EDGE Security Panel
58
(09) 24-Hour
Fire †
This sensor type is continuously armed
24-hours-a-day. A sensor programmed to this
type will trigger the local alarm re sounder
and the bell output regardless of the mode
the system is in. This sensor type is typically
used for wireless smoke detectors. This
sensor type is always active and cannot be
bypassed.
(10) Interior
with Delay
This sensor type operates as a delayed
sensor when the system is armed in the Away
mode, and when triggered, will start the Entry
Delay 1 timer. If the system is armed in Away
mode with no Entry Delay (armed instant),
this sensor type will trigger an instant alarm.
If the system is armed in Stay mode (or Stay
mode with no Entry Delay), this sensor type
will be bypassed.
(14) 24-Hour
Carbon
Monoxide †
This sensor type is continuously armed
24-hours-a-day. A sensor programmed to this
type will trigger the local alarm pulse sounder
and the bell output regardless of the mode
the system is in. This sensor type is typically
used for wireless carbon monoxide detectors.
This sensor type is always active and cannot
be bypassed.
(16) 24-
Hour Fire
Verication †
This sensor type is continuously armed
24-hours-a-day. A sensor programmed to this
type can trigger the local alarm re sounder
and the bell output regardless of the mode
the system is in. This sensor type is typically
used for wireless smoke detectors. This
sensor type is always active and cannot be
bypassed.
For verication, this sensor type must be
violated twice in two (2) minutes, or remain
violated for 30 seconds. If any other re
sensor (veried sensor type or not) violates
within two (2) minutes, both sensors will
cause a re alarm.
(23) No
Response
Type
This sensor type is a special zone that can
be monitored for activity or inactivity by the
Central Station. It does not affect security
system status.
(24) Silent
Burglary
This sensor type is for silent triggering the
burglary alarm with perimeter doors and
windows that will not be used to enter or exit
the protected premises while the system is
armed. The Control Panel’s sounder and the
bell output will not activate.
An instant silent alarm will occur when this
type of sensor is triggered with the system
armed in either the Stay or Away mode.
(32) Remote
Device
Special Zone with Wireless Repeater
† Indicates sensor types that are not allowed for hardwired loops.
Sensor Equipment Type
For wireless zones that have been specied as being on one of these
equipment types (for example, 04-Interior Follower, 06-24-Hour Silent
Alarm, 07- 24-Hour Audible Alarm, 08 24-Hour Auxiliary Alarm, 10-
Interior with Delay, 23-No Response Type), installers must also select
one of the Sensor Equipment Types listed below.
Sensor Type Sensor Equipment Type
(04) Interior Follower Contact, Motion
(06) 24-Hour Silent Alarm Contact, Emergency
(07) 24-Hour Audible Alarm Contact, Emergency
(08) 24-Hour Auxiliary Alarm
Contact, Freeze, Water,
Temperature, Emergency
(10) Interior with Delay Contact, Motion
(23) No Response Type Contact, Motion
This zone type is selected by the installer when pairing the panel with
peripheral devices that can utilize localized troubles (such as RF jam,
low battery, tamper, or AC loss detected by the peripheral device). This
sensor is continuously active and will cause a trouble at the panel for
all problem conditions. When the panel is in an armed state, this sensor
type will cause an alarm for TAMPER and RF JAM. All trouble conditions
will be sent to the monitoring station if reporting is enabled with the
exception of AC LOSS. This will only be displayed at the panel.
Equipment Codes
Required for all wireless zones, keyfobs, and keypads.
Wireless Zones—Equipment Codes
0000-Other
2862-eSeries Thin Door/Window Contact
0862-2GIG Thin Door/Window Contact
2863-eSeries Recessed Door Contact
0863-2GIG Recessed Door Contact
2869-eSeries PIR with Pet Immunity
0869-2GIG PIR with Pet Immunity
2864-eSeries Glass Break Detector
0864-2GIG Glass Break Detector
2058-eSeries Smoke Detector (USA)
1058-2GIG Smoke Detector
